KONTAKTOR 9A AC-3 24VDC LAV EFFEKT
Produktnummer: 100-C09EJ10
Produktstatus:
inkl. mva.
100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Line Side, 9A, 1 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack
Contactor, 9 A, IEC, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open Poles, 24V DC Electronic, 1 NO Contacts & 0 NC Contacts, SinglePack, Line Side Coil Termination, Screw Terminals, Motor Load
| Spesifikasjoner | |
|---|---|
| Connection | Screw Terminals |
| 1-Phase HP (60 Hz) 115V Rating | 0.5 |
| 1-Phase HP (60 Hz) 230V Rating | 1.5 |
| 3-Phase HP (60 Hz) 575V Rating | 7.5 |
| Terminal Type | Screw Terminals |
| Rated Operating Current, AC-3 | 9A |
| Coil Voltage | 24V DC Electronic Coil |
| Coil Termination | Line Side |
| Contact Configuration | 1 N.O. 0 N.C. Auxiliary Contact Configuration |
| Package Quantity | 1 |
| Electrical Standards | UL |
| Utilization Category | AC-3 Squirrel-cage motor starting and stopping |
| Actual Life | Actual Life Cannot be Calculated (more information)... |
| 100-C or 104-C Contactor | 1_ |
| Front Mounted Auxiliary Contact | None |
| Left Side Auxiliary Contact | None |
| Right Side Auxiliary Contact | None |
| Interlock | None |
| Opprinnelsesland | CH |
| Tolltariffnummer | 85364190 |
| Lengde | 9.271 |
| Høyde | 4.953 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 100-td013_-en-p.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
3D Mechanical Drawing (PDF) Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
2D Drawing (PDF) Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
Repair Parts List Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
2D Drawing (DWG/DXF) Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
MCS 100-C Contactor Photo Filnavn: en-US Filtype: image/png |
Last ned | |
|
ABMSA010.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA010.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA010.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
ABMSA010.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned | |
|
ABMSA011.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
ABMSA011.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
ABMSA011.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
ABMSA011.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned |
