KONTAKTOR 9A AC3 230VAC SPOLE.1NC

Produktnummer: 100-C09KF01
Produktstatus:


inkl. mva.

100-C IEC Contactor, 230V 50/60Hz, Screw Terminals, Line Side, 9A, 0 N.O. 1 N.C. Auxiliary Contact Configuration, Single Pack

Contactor, 9 A, 230V 50/60 Hz, AC, 3 Normally Open Poles, 230V AC 50/60 Hz, 0 NO Contacts & 1 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Egenskaper for produkt/familie

  • Meets IEC, UL, and CSA standards requirements
  • RoHs compliant
  • Provides reversible coil terminations (line or load side)
  • Provides IP2X finger protection
  • Offers common accessories for all contactor sizes
  • Includes reversible coil terminations (line or load side)
  • Includes electronic and pneumatic timing modules
  • Includes built-in surge suppression with DC coils
  • Includes space-saving coil-mounted control modules
  • Provides front and side mounting of auxiliary contacts
Spesifikasjoner
Connection Screw Terminals
1-Phase HP (60 Hz) 115V Rating 0.5
1-Phase HP (60 Hz) 230V Rating 1.5
3-Phase HP (60 Hz) 575V Rating 7.5
Terminal Type Screw Terminals
Rated Operating Current, AC-3 9A
Coil Voltage 230V 50/60Hz
Coil Termination Line Side
Contact Configuration 0 N.O. 1 N.C. Auxiliary Contact Configuration
Package Quantity 1
Electrical Standards UL
Utilization Category AC-3 Squirrel-cage motor starting and stopping
Actual Life Actual Life Cannot be Calculated (more information)...
100-C or 104-C Contactor 2_
Front Mounted Auxiliary Contact None
Left Side Auxiliary Contact None
Right Side Auxiliary Contact None
Interlock None
Opprinnelsesland CH
Tolltariffnummer 85364900
Lengde 9.401
Høyde 5.001
Livssyklus Active
