KONTAKTOR 9A AC3 24V50/60.1NO

Produktnummer: 100-C09KJ10
Produktstatus:


inkl. mva.

100-C IEC Contactor, 24V 50/60Hz, Screw Terminals, Line Side, 9A, 1 N.O. 0 N.C. Auxiliary Contact Configuration, Single Pack

Contactor, 9 A, IEC, 24V 50/60 Hz, AC, 3 Normally Open Poles, 24V AC 50/60 Hz, 1 NO Contacts & 0 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Egenskaper for produkt/familie

  • Includes built-in surge suppression with DC coils
  • Includes reversible coil terminations (line or load side)
  • Includes electronic and pneumatic timing modules
  • Provides reversible coil terminations (line or load side)
  • Meets IEC, UL, and CSA standards requirements
  • Provides IP2X finger protection
  • Provides front and side mounting of auxiliary contacts
  • RoHs compliant
  • Includes space-saving coil-mounted control modules
  • Offers common accessories for all contactor sizes
Spesifikasjoner
Connection Screw Terminals
1-Phase HP (60 Hz) 115V Rating 0.5
1-Phase HP (60 Hz) 230V Rating 1.5
3-Phase HP (60 Hz) 575V Rating 7.5
Terminal Type Screw Terminals
Rated Operating Current, AC-3 9A
Coil Voltage 24V 50/60Hz
Coil Termination Line Side
Contact Configuration 1 N.O. 0 N.C. Auxiliary Contact Configuration
Package Quantity 1
Electrical Standards UL
Utilization Category AC-3 Squirrel-cage motor starting and stopping
Actual Life Actual Life Cannot be Calculated (more information)...
100-C or 104-C Contactor 1_
Front Mounted Auxiliary Contact None
Left Side Auxiliary Contact None
Right Side Auxiliary Contact None
Interlock None
Opprinnelsesland CH
Tolltariffnummer 85364190
Lengde 9.6
Høyde 5.0
Livssyklus Active
