Kapasitiv sensor, justerbar, skjermet metall
Produktnummer: 875C-M2NP12-A2
Produktstatus:
inkl. mva.
Proximity Sensor, 3-Wire DC Plastic Face/Nickel Plated Brass Barrel, 12mm Diameter:Threaded, 2.5mm Sensing Distance, Shielded, N.O., Source (PNP) Output, PVC Cable
Capatitive Proximity Sensor, Cylindrical Nickel Plated, Standard Barrel Housing, 12 mm Barrel Diameter, DC Shielded, 2 mm Sensing Distance, Normally Open Sourcing, 2 M PVC Cable
Egenskaper for produkt/familie
- Metal, nonmetal solid and liquid sensing capability
- Normally open or normally closed output
- Shielded metal (875C) and unshielded plastic (875CP) models
- Short circuit, overload, reverse polarity, transient noise protection
- Adjustable sensing distance
| Spesifikasjoner | |
|---|---|
| Output Configuration | N.O., Source (PNP) |
| Proximity Sensor Type | 3-Wire DC Plastic Face/Threaded Nickel Plated Brass Barrel |
| Barrel Diameter | 12mm Threaded |
| Nominal Sensing Distance | 2.5mm, Shielded |
| Connection Type | 3-Wire DC PVC Cable (3 Conductors) |
| Type | 3-Wire DC Plastic Face/Threaded Nickel Plated Brass Barrel |
| Voltage Rating | 10-48V DC |
| Output | N.O., Source (PNP) |
| Opprinnelsesland | US |
| Tolltariffnummer | 85365080 |
| Lengde | 11.989 |
| Høyde | 3.404 |
| Livssyklus | Active |
