MSR127TP, 24VAC/DC, Auto/manuell reset
Produktnummer: 440R-N23132
Produktstatus:
inkl. mva.
440R Single Function Safety Relays, 1 N.C.,3 N.O., , 24V DC , Removable,Automatic/Manual Reset
Safety Relay, MSR127TP, 24V AC/DC, Automatic/Manual, Removable, 22.5MM Housing Width, Infinite, One 2 N.C. Input, One LC Input, 3 Safety Output, 1 N.C. Aux. Relay Output, CAT 4 Rated
Egenskaper for produkt/familie
- Ideal for relatively small safety applications and single zone control
- Offers compact packages with removable terminals
- Available in electromechanical versions or solid-state models
| Spesifikasjoner | |
|---|---|
| Output | 3 N.O. |
| Single Wire Safe Input | N/A |
| Logic Configuration | None |
| Immediate Safety Outputs | 3 N.O. |
| Immediate Auxiliary Outputs | 1 N.C. |
| Delayed Safety Outputs | N/A |
| Single Wire Safe Output | N/A |
| Power Supply | 24V DC |
| Removable Terminals | Removable |
| Reset | Automatic/Manual Reset |
| Relay Model Selected | MSR127RP/TP |
| Contact Rating | DC-13 6 A/24V DC, 0.1Hz |
| Enclosure | 22.5 mm |
| Standard | CE/cULus/BG |
| Opprinnelsesland | DO |
| Tolltariffnummer | 85364190 |
| Lengde | 10.49 |
| Høyde | 2.997 |
| Livssyklus | Active |
| Nedlastinger | ||
|---|---|---|
|
3-Dimensional STEP model (STP) Filnavn: en-US Filtype: application/x-zip-compressed |
Last ned | |
|
2-Dimensional Drawing (DXF) Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
2-Dimensional Drawing (PDF) Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
Photo Filnavn: en-US Filtype: image/png |
Last ned |
