POINT I/O 8 Point Digital Input Module
Produktnummer: 1734-IB8
Produktstatus:
inkl. mva.
24V Dc 8 Channel Sink Input Module
Input Module, POINT I/O, Digital, DC, 8 Points Sinking 24VDC Input, Open Style, DIN Mounted
Egenskaper for produkt/familie
- Removable wiring system saves time and money during installation and troubleshooting
- Configurable modules
- Available with conformal coating
- Add-on-Profiles in the Studio 5000 Logix Designer® application provide smooth integration into Integrated Architecture systems
- Modular design lets you independently select the I/O, termination style, and network interface
- Modules slide together for easy install and uninstall for easier maintenance
- Auto Device Replacement (ADR) reduces downtime
- Removal and Insertion Under Power (RIUP) lets you replace modules while the system is in operation
- Mount horizontally or vertically, with no de-rating required
- Comprehensive diagnostics and configurable features makes POINT I/O™ easy to apply
| Spesifikasjoner | |
|---|---|
| Sub Brand | POINT |
| Type | DC Input Sink Module |
| Special Features | Standard |
| Application | In-Cabinet |
| Power Supply | 24V DC |
| Mounting | Din-rail |
| Enclosure | None (open-style) |
| Temperature Rating | -20...55 °C (-4...131 °F) |
| Input | 8 Point |
| Isolation Voltage | 50V. Tested to withstand 2500V DC for 60 s |
| POINT Digital DC Input Modules | 24V Dc 8 Channel Sink Input Module |
| Opprinnelsesland | SG |
| Tolltariffnummer | 85389099 |
| Lengde | 1.905 |
| Høyde | 6.35 |
| Livssyklus | Active |
| Datablad | ||
|---|---|---|
|
Spec Sheet Filnavn: 1734-in051_-en-e.pdf Filtype: application/pdf |
Last ned |
| Nedlastinger | ||
|---|---|---|
|
3-Dimensional STEP model (STP) Filnavn: en-US Filtype: application/x-zip-compressed |
Last ned | |
|
2D Dimension Drawing (DWG or DXF) Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
Wiring Diagram Filnavn: en-US Filtype: application/x-msmetafile |
Last ned | |
|
Wiring Diagram (DWG) Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
ABIOR280.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
ABIOR280.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
ABIOR280.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
ABIOR280.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned | |
|
ABIOR281.dwg Filnavn: en-US Filtype: image/vnd.dwg |
Last ned | |
|
ABIOR281.dxf Filnavn: en-US Filtype: image/vnd.dxf |
Last ned | |
|
ABIOR281.pdf Filnavn: en-US Filtype: application/pdf |
Last ned | |
|
ABIOR281.wmf Filnavn: en-US Filtype: application/x-msmetafile |
Last ned |
