Rekkeklemme 2.5mm2 skru blå
Produktnummer: 1492-J3-B
Produktstatus:
inkl. mva.
1492-J IEC Terminal Block, One-Circuit Feed-Through Block, 2.5 mm (# 24 AWG - # 12 AWG), Standard Feedthrough, Blue,
Terminal Block, Screw Connection, Feed Through, 5.1 x 60 x 39.5mm (0.20 x 2.36 x 1.56 in), 1 Pole, Blue, Pkg. Qty. of 100, VOLTAGERATING UR - 600V AC/DC, CSA - 600V AC/DC, IEC - 800V AC/DC, ATEX 550V AC/DC, MAXIMUM CURRENT RATING UR - 25A, CSA - 20A, I
Egenskaper for produkt/familie
- Four-sided funnel wire guides
- Easy installation or removal from both sides of DIN Rail
- Copper current bar and tin-plated surface
- Wide range of accessories available
- Compatible with several high visibility snap-in marker cards
- Self-locking screw type clamp design
- Tin-plated terminal and zinc chromate steel screws
- Backed-out screws
- Counter-sinking of clamping screws
- Finger-safe housing
| Spesifikasjoner | |
|---|---|
| Special Features | Standard Feedthrough |
| Base Block Style | Standard Feed-Through Blocks |
| Base Block Type | One-Circuit Feed-Through Block |
| Features | Standard Feedthrough |
| Maximum Wire Size & Rating | UL: 30-12 AWG (25A @600V AC/DC) CSA: 26-12 AWG (20A @600V AC/DC) IEC: 2.5mm² (24A @800V AC/DC) EEx e II: 2.5mm²/20-14 AWG (21A @ 550V AC/DC) |
| Color | Blue |
| Opprinnelsesland | DE |
| Tolltariffnummer | 85369095 |
| Lengde | 0.305 |
| Høyde | 5.207 |
| Livssyklus | Active |
